Chemical components of welding wire (%)
| C | Mn | Si | Cr | Ni | Mo | P | S | Cu | |
| Range | ≤0.03 | 1.00-2.50 | 0.30-0.65 | 23.00~25.00 | 12.00~14.00 | ≤0.75 | ≤0.030 | ≤0.030 | ≤0.75 |
| Test | 0.02 | 1.95 | 0.45 | 23.90 | 12.92 | 0.035 | 0.008 | 0.011 | 0.21 |
Mechanical properties of deposited metal:
| Tensile strength Rm (Mpa) | Elongation ratio (%) | Shielding gas | ||||||
| Test | 590 | 39 | 98%Ar+2%O₂ | |||||
Reference current (DC+)
| Diameter (mm) | φ0.8 | φ1.0 | φ1.2 | |||
| Welding Current (A) | 70~150 | 100~200 | 140~220 | |||
Precautions:
- Shielding gas: pay attention to the purity of shielding gas, it is recommended to keep the mixed ratio at Ar + 1~3% O₂.
- Gas flow: 20~25L/min.
- Dry extension length: 15~25min.
- The rust layer, moisture, oil stain, dust, etc on the welding part shall be clearly removed.
Welding Position: H, OH, HF, F, VD, VU
